Elos + SHR 640 + ND Yag Laser + RF 4 in 1 Multi-Purpose Beauty Machine

Elos+SHR 640+ND YAG Laser+RF 4 in 1 Multi-Purpose Beauty Machine

企业微信截图 17292447584377

Most advanced 4 in 1 Laser.
With 1 machine, it covers 10 functions!

– Super hair removal
– Acne treatment
– Photo rejuvenation
– Skin whitening
– Spider vein treatment
– Pigmentation treatment
– Tattoo removal
– Carbon peeling
– Wrinkle removal
– Body lifting
Specification
Specification
Elight Elos
SHR
Nd:Yag Laser
RF
Power supply
2000W
2000W
500W
/
Energy/max
1-50J/cm2
1-50J/cm2
1000mJ
1-100W
Wavelength
Standard:16*60mm,16*35mm,Optional:16*20mm Standard:16*60mm,16*35mm,Optional:16*20mm
532/1064/1320nm
/
Spot size
standard: 480nm 530nm 640nm, Optional:560nm 690nm Fixed 640-1200nm
6mm
20/28/35mm
Pulse duration
1-50J/cm2(without filter) 1-25J/cm2
10ns-20ns
/
Pulse interval
/
/
/
0-3000ms
Frequency
1-10Hz
Cooling Level
1-5 level
Cooling System
Air + Water + Wind + TEC + Sapphire sking contact cooling
Operation
10”TFT True Color Touch Screen
Electrical input
90-130V, 50/60HZ or 200-260V, 50HZ

Independent power supply for each system. This well ensures each system has strong and stable energy.

Inside structure is very reasonable and every line is clear. All the spare parts are fixed to metal shelf.
* 2000W power supply for E-light/ Elos system.
* 2000W power supply for SHR system.
* 500W power supply for ND yag laser system
* 100W power supply for RF system
Spare parts we use
* UK lamp, US laser bars
* 8L big water tank with water level monitor
* 2 Korea imported water filters
* Schneider brand switch
* 4 Japan imported big fans + 2 big radiators
* Latest brushless DC water pump with lift 15m
* Pulse water switch to monitor water flow
* Stainless steel board between connector and internal
机器零件
Handle Details

LED screen SHR handle


3 different size treatment tip

SHR treatment tips of different sizes can meet the hair removal needs of other body parts. For large-area hair removal, use a large-area treatment tip, and for small-area hair removal, use a small-area treatment tip.

For example, for leg hair removal and back hair removal, it is more suitable to use a large size 16*60mm. For hair removal around the lips of women and around the beard of men, it is more suitable to use a small-size hair removal. It is no longer a fixed size, which is particularly limited. 3 different-size treatment tips are more flexible and convenient during use.

The big LED screen on SHR

Design LED screen on SHR handle, it is nicer and more convenient. It is people’s pursuit of modern design, and they prefer products with a strong sense of technology, which are more high-end, more beautiful, and more popular. During use, the parameters can be adjusted directly through the LED screen handle, which is faster and more efficient. All parameters can be adjusted through the BIG LED screen! No need to adjust the parameters on the machine screen anymore!

360° Super Cooling

Update the TEC cooling part, it is the same TEC cooling part as with the Diode laser machine, it is more nice cooling results. If you are not satisfied with the cooling strength of the old IPL handle, you are welcome to try the newest SHR handle, No.1 cooling results now!

LED screen IPL


IPL is with 5 filters, 480nm, 530nm, 590nm, 640nm, 690nm

Put different filters, it will have different functions

480nm  filter is for Acne treatment

530nm filter is for skin rejuvenation

590nm filter is for pigment remove

640nm filter is for yellow skin hair remove

690nm filter is for dark skin hair remove

Intelligent Recognition IPL

intelligent IPL handle

Intelligent Recognition of the correct treatment tips, this is very convenient, automatically recognizes whether it is a large head, a medium head, or a small head, and gives the parameters of the corresponding treatment head, eliminating the trouble of manually setting parameters, saving time and being more intelligent.

The three different sizes of treatment heads also meet the needs of treating different parts of the body, which is more humane and more reasonable. The LED screen SHR IPL, you will like it also, 100%

ND 详情内主图 1

ND Yag Laser Handle : 3 Million Shots, UK Lamp
* Super long life of 3 million shots, at least 5-10 times longer than others!
* UK xenon lamp + Φ6 rod
* Big and round spot size, very uniform energy output

We offer 3 tips to cover all customer needs.
532nm wavelength: get rid of freckles, eyebrow tattoo, failed eye line tattoo, tattoo , lips line, pigment, telangiectasia in shallow red, brown and pink and etc. light color
1064nm wavelength: get rid of freckles and yellow brown spot, eyebrow tattoo, failed eye line tattoo, tattoo, Birthmark and Nevus of Ota, pigmentation and age spot, nevus in black and blue, scarlet red, deep coffee and etc. deep color.
1320nm wavelength: shrink pores removal, poblackhead removal, skin tightening and whitening, skin rejuvenation, wrinkle removal.

RF 详情内主图

RF Handle : Unlimitted Shots

3 Treatment tips for different area:
* Small (21mm): for eye round treatment
* Middle (27mm): for face treatment
* Big (36mm): for body treatment

RF-lifting skin tightening is a modern treatment based on radio waves. It’s a safe and effective and
does not require downtime. Patients can see skin tightening immediately after treatment. With
proper skin care, results can last for two to three years.
HD Interface
Diode laser3
Elight parameter
IPL functions
Q switch3
RF
Super Feedback
Diode Feedback
治疗效果 IPL
治疗效果 ND
治疗效果 RF

Company profile:

Beijing STELLE LASER Technology Co Ltd is the leading beauty machine manufacturer from China which established
in 2010. Our produts cover full range beauty equipments such as Diode laser 808nm, Q-switch Nd yag laser, IPL
SHR E-light and multifunctional beauty machine combining above handles. In China, we are first factory to start
combine Diode laser handle with other handle, we open the market, because it is hard to combine Diode laser
handle with other handles, before 2020, only our factory can do Diode laser 2 in 1,Diode laser 3 in 1, Diode laser
4 in 1. Now China market a few company can do Diode laser 2 in 1, such as Diode + Nd yag, Diode + ipl, But
they can’t do Diode 3 in 1 machine, such as Diode + Nd yag + Ipl, They also can’t do Diode 4 in 1 Laser, such as
Diode + Nd yag + E-light + RF machine, and we can do it about 11 years ago, they can only do it in 2020,  their
machine qulity is not stable, machine quality not high, after-sale problem is high, but we already developent
many years, now our machine is stable and high quality, no after-sale problem. We are very professional
production diode laser machine. We have three different diode laser handles. We have 300w 500W 600W
800W 1000W 1200W 1400W 1600W. We have portable diode laser 808nm + Ipl and Diode laser 808nm +
Nd yag, vertical Diode + Ipl + laser 980nm and Diode + Nd Yag + laser 980nm, and Diode + Nd Yag +
E-light + laser 980nm, and Diode + Nd Yag + E-light + RF + laser 980nm, only our factory can do it in China.
